Additional information
Make Model
CTX 700D / DCT
Year
2014
Engine
Four stroke , Parallel twin, SOHC, 4 valves per cylinder
Capacity
670 cc / 40.8 cu-in
Bore x Stroke
73 × 80 mm
Cooling System
Liquid-cooled
Compression Ratio
10.7:1
Induction
PGM-FI electronic fuel injection
Ignition
Computer-controlled digital transistorised with electronic advance
Starting
Electric
Max Power
38.1 kW / 51.1 hp @ 6250 rpm
Max Torque
62 Nm / 46 lb-ft @ 4750 rpm
Clutch
Wet Multiplate
Transmission
Automatic six speed with two modes and a manual mode
Final Drive
Chain
Frame
Rigid tube steel diamond
Front Suspension
41 mm telescopic forks,
Front Wheel Travel
120 mm / 4.3 in
Rear Suspension
Single monoshock damper,
Rear Wheel Travel
120 mm / 4.3 in
Front Brakes
Single 320 mm hydraulic disc 3 piston calipers and sintered metal pads
Rear Brakes
Single 240 mm hydraulic disc 1 piston caliper and sintered metal pads
Front Tyre
120/70-ZR17
Rear Tyre
160/60-ZR17
Rake
27˚
Trail
110 mm / 4.4 in
Dimensions
Length 2195 mm / 86.4 in Width 790 mm / 31.1 in Height 1440 mm / 56.6 in
Wheelbase
1525 mm / 60.2 in
Seat Height
718.8 mm / 28.3 in
Wet Weight
234 kg / 516 lbs
Fuel Capacity
12 Litres / 3.17 gal
