#5249 Bike Triumph Tiger Sport 660
Model: Tiger Sport 660
Year: 2022
Capacity: 660 cm3
Mileage: 3101 km.
in
Additional information
Make Model
Tiger Sport 660
Year
2022
Engine
Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder, 240° firing order
Capacity
660 cc / 40.2 cu-in
Bore x Stroke
74.0 x 51.1 mm
Compression Ratio
11.95:1
Cooling System
Liquid cooled
Exhaust
Stainless steel 3 into 1 header system with low single sided stainless steel silencer
Emission
Euro-5
Induction
Multipoint sequential electronic fuel injection with electronic throttle control
Starting
Electric
Max Power
80 hp / 60 kW @ 10250 rpm
Max Power A2 Restriction
46 hp / 35 kW @ 8750 rpm
Max Torque
64 Nm / 47 lb-ft @ 6250 rpm
Max Torque A2 Restriction
59 Nm / 43.5 lb-ft @ 5250 rpm
Clutch
Wet, multi-plate, slip and assist
Transmission
6 Speed
Final Drive
X-ring chain
Frame
Tubular steel perimeter frame, twin-sided, fabricated steel Swingarm
Front Suspension
41mm Showa upside down separate function forks (SFF)
Front Wheel Travel
150 mm / 5.9 in
Rear Suspension
Showa monoshock RSU, with remote hydraulic preload adjustment
Rear Wheel Travel
1504 mm / 5.9 in
Front Brakes
2x 310mm discs, Nissin 2-piston sliding calipers
Rear Brakes
Single 255mm disc, Nissin single-piston sliding caliper
ABS System
Standard
Wheels
5 Spoke cast aluminum
Front Rim
3.5 x 17
Rear Rim
5.5 x 17
Front Tyre
120/70 - R17 (58W)
Rear Tyre
180/55 - R17 (73W)
Rake
23.1°
Trail
97.1 mm / 3.8 in
Dimensions
Length 2071 mm / 81.5 in Width 834 mm / 32.8 in Height 1398 mm / 55 in - 1315mm / 51.7 in (high / low screen position)
Wheelbase
1418 mm / 55.8 in
Seat Height
835 mm / 32.8 in
Wet Weight
206 kg / 454 lbs
Fuel Capacity
17.2 Litres / 4.5 US gal
Instruments
Multi-function instruments with colour TFT screen
