Additional information
Make Model
R 1200R Touring Special
Year
2010
Engine
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Capacity
1170 cc / 71.4 cu in
Bore x Stroke
101 x 73 mm
Cooling System
Air/Oil-cooled
Compression Ratio
11.0:1
Induction
Electronic intake manifold injection BMS-K
Ignition
Digital engine management
Starting
Electric
Alternator
Three-phase alternator 720 W
Battery
12 V / 14 Ah, maintenance-free
Max Power
80 kW / 109 hp @ 7500 rpm
Max Torque
115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm
Clutch
Single disc dry clutch, hydraulically actuated
Transmission
6 Speed
Final Drive
Shaft
Gear Ratio
1st 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 0.065 / 5th 0.939 / 6th 0.848
Frame
Tubular steel spaceframe, load-bearing engine
Front Suspension
BMW Motorrad Telelever; stanchion diameter 41 mm, central spring strut
Front Wheel Travel
120 mm / 4.7 in
Rear Suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Rear Wheel Travel
140 mm / 5.5 in
Front Brakes
2 x 320mm discs, ABS
Rear Brakes
Single 265mm disc, ABS
Wheels
Cast aluminium wheels
Front RIM
3.50 x 17'
Riear Rim
5.50 x 17
Front Tyre
120/70-ZR 17
Rear Tyre
180/55-ZR 17
Castor
119.1 mm / 4.7 in
Steering Head Angle
62.9°
Dimensions
Length 2145 mm / 84.4 in Width 906 mm / 35.6 in (incl. mirrors) Height 1273 mm / 50.1 in (excl. mirrors)
Wheelbase
1495 mm / 59.1 in
Seat Height
800 mm / 31.4 in
Dry Weight
198 kg / 436.5 lbs
Fuel Capacity
18 Litres / 4.7 US gal
Consumption Average
7.2 L/100 km / 13.8 km/l / 32.4 US mpg
Standing 1/4 Mile
11.9 sec / 187.2 km/h / 116.3 mph
Standing 0 - 1000m
22.6 sec / 213 km/h / 132 mph
Top Speed
219.6 km/h / 136 mph
