Additional information
Make Model
CB 650R
Year
2021
Engine
Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder
Capacity
649 cc / 39.6 cu-in
Bore x Stroke
67 x 46mm
Compression Ratio
11.6:1
Cooling System
Liquid cooled
Induction
PGM-FI electronic fuel injection, 32mm bore
Ignition
Digital transistorized with electronic advance
Starting
Electric
Max Power
70kW / 94 hp @ 12000rpm
Max Torque
63Nm / 46.4 lb-ft @ 8500rpm
Clutch
Multiplate wet, with slipper clutch
Transmission
Close-ratio 6 Speed
Final Drive
#525 chain, 15T/42T
Frame
Steel diamond
Front Suspension
41mm Showa separate function front fork big piston (SFF-BP) USD forks
Front Wheel Travel
120 mm / 4.7 in
Rear Suspension
Monoshock damper with 7 stage adjustable preload, 43.5mm stroke
Rear Wheel Travel
127 mm / 5.0 in
Front Brakes
2x 310mm floating discs dual four-piston, radial-mount Nissin hydraulic calipers
Rear Brakes
Single 240mm disc single one-piston hydraulic caliper
ABS
2-channel ABS
Wheels
Hollow section 6-spoke cast aluminium
Front Tyre
120/70-ZR17
Rear Tyre
180/55-ZR17
Rake
25.5º
Trail
101 mm / 3.9 in
Dimensions
Length 2130 mm / 83.8 in Width 780 mm / 30.7 in Height 1075 mm / 42.3 in
Wheelbase
1450 mm / 57.0 in
Seat Height
810 mm / 31.9 in
Ground Clearance
150 mm / 5.9 in
Wet Weight
202.5 kg / 446.4 lbs
Fuel Capacity
15.5 Litres / 4.1 US gal
