Additional information
Make Model
DN-01
Year
2008-10
Engine
Four stroke, 52°V-Twin, SOHC. 4 valve per cylinder
Capacity
680 cc / 41.4 cu-in
Bore x Stroke
81 x 66 mm
Cooling System
Liquid cooled
Compression Ratio
10.0:1
Lubrication
Wet sump
Induction
PGM-F1 Electronic fuel injection40mm throttle bedews
Ignition
Digital transistorized with electronic advance
Starting
Electric
Max Power
45 kW / 61 hp @ 7500 rpm
Max Torque
64 Nm / 6.5 kgf-m 6000-
Clutch
HFT Antennal hydraulic control
Transmission
Continuously variable, hydro-mechanical two-mode automatic with six-speed manual mode
Final Drive
Shaft
Frame
Double cradle steel tube
Front Suspension
41mm Telescopic forks
Front Wheel Travel
106 mm / 4.0 in
Rear Suspension
Single conventional dampers with 7-step adjustment spring preload
Rear Wheel Travel
120 mm / 4.7 in
Front Brakes
130/70 ZR17
Rear Brakes
190/50 ZR17
Front Tyre
2x 296 discs 3 piston caliper
Rear Tyre
Single 276mm disc 2 piston caliper
Rake
28.5°
Trail
110 mm / 4.5 in
Dimensions
Length 1830 mm / 72.0 in Height 1020 mm / 40.0 in
Wheelbase
1609 mm / 63.3 in
Seat Height
713 mm / 28.1 in
Dry Weight
268 kg / 501 lbs
Fuel Capacity
15 Litres / 3.4 US gal
Consumption Average
19.2 km/lit
Standing 1/4 Mile
15.1 sec
Top Speed
182.9 km/h / 113.6 mph
