Additional information
Make Model
F 800GS Trophy
Year
2012
Engine
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Capacity
798 cc / 47.7 cub. in.
Bore x Stroke
82 x 75.8 mm
Compression Ratio
12.0:1
Cooling
Liquid cooled
Induction
Electronic intake injection, ∅45mm throttle bodies
Ignition
Knock control and oxygen sensors.
Starting
Electric
Max Power
62.5 kW / 85 hp @ 7500 rpm
Max Torque
80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm
Clutch
Multiplate-plate in oil bath
Transmission
6 Speed
Final Drive
Chain
Gear Ratio
1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96
Final Drive Ratio
1:2.6
Frame
Tubular frame in steal partly carrying the engine
Rake
26°
Trail
117 mm / 9.1 in.
Front Suspension
∅43mm Marzocchi upside down forks
Front Wheel Travel
230 mm / 9.1 in.
Rear Suspension
Double strut swing arm aluminium coast in one piece
Rear Wheel Travel
215 mm / 8.5 in.
Front Brakes
2 x ∅300mm discs, 4 piston calipers
Rear Brakes
Single ∅265mm disc, 2 piston caliper
Wheels
Wire spoke
Rim Front
2.15 x 21"
Rim Rear
4.25 x 17"
Front Tyre
90/90 - 21 54V
Rear Tyre
150/70 - 17 69V
Dimensions
Length 2320 mm / 91.3 in Width 945 mm / 37.2 in (incl. mirrors) Height 1350 mm / 53.1 in (excl. mirrors)
Seat Height
880 mm - 850 mm / 34.6 in. - 33.5 in.
Wheel Base
1577 mm / 62.1 in
Dry Weight
177.8 kg / 392 lbs
Wet Weight
207 kg / 456 lbs
Fuel Capacity
16 Litres / 4.2 US gal.
Consumption Average
5.1 l/100km / 19.6 km/l / 45.9 US mpg
Average Tank Distance
312 km / 194 miles
Standing 1/4 Mile
12.5 sec
Top Speed
199.0 km/h / 124 mph
